Fast Speed Automatic Intelligent Rectangular Food Paper Bowl Making
Machine
Specification:
MODEL | SMD-80C |
SPEED | 40-45PCS/MIN |
MAX BOWL SIZE | 180(Top length) * 160 (btm length)*95 MM(Height) |
MATERIAL | 135-450GRAM |
CONFIGURATION | ULTRASONIC&HOT AIR |
OUTPUT | 380V/220V,60HZ |
AIR COMPRESSOR | 0.5 M³/Min |
NET WEIGHT | 6.2 TONS |
MACHINE SIZE | 3200×2100 ×1700 MM |
COUNTER SIZE | 1200×1200 ×1760 MM |
Description:
SMD-80C is a Square and Rectangular Paper Bowl Making machine,which
is designed By HAINING CHENGDA MACHINERY CO.,LTD,
It can produce both single and Double PE coated paper Bowls. As
technology development, it will take place of the formally machines
in market day by day.
Detail:
Hot air system and protect system: 2 set of hot air systems can decrease the rate of leakage. Our
factory using the whole set of Leister hot air system with
protection system. And our system sets up on the fixed plate, do
not moving during production. Almost impossible to damage. Also the
only one have the protect system that hot parts will go down, keep
the distance with paper cup and cup mould when the machine stop.
Servo motor: Service for bottom paper feeding. The feature of runs more stable
and accuracy, reduce the waste of bottom paper. Servo motor is made
in Japan by MITSUBISHI.
Product Advantages:
1.2 sets of original imported hot air system Leister guarantee the
stability of heating.
2.Ultrasonic seal the paper cup body,can produce both single and
double PE coated paper.
3.Panasonic photoelectricity checking the every part and report.
4.Open cylindrical can divide locating,heigh precision.
5.Automatically Oil lubrication system .
6.Gear work, long life for machinery
7.Inspection system by camera
8.Photoelectricity to track every step
Applications:
Square paper bowl, soup bowl, noodle bowl...
About Us:
Haining Chengda Paper Cup Machinery CO.,Ltd is established in year
1998,as Chinese earliest
paper cup machine manufacturer--design,research,manufacture,sell
and serve , we have developed,
matured and specialized in machine types as below,
--Middle speed paper bowl machine SMD-80B 70-80cups/min
--Middle speed double wall paper cup machine SMD-80A 80-100cups/min
--High speed paper cup machine SMD-90 100-120cups/min
Company Advantages:
Quality assurance both for our products and service for
after-sales.
Favorable price.
Great variety of products.
Attractive design.
Environment Friendly Technology
OEM and ODM service provided.
Exhibition Show:
FAQ:
1. Is your company a factory or trading company?
Our company is a factory, also have export license.
2. Where is your factory located? How can I visit there?
Our factory is located in haining City, Zhejiang Province, China,
about 1.5 hours by car from Shanghai .All our clients, from home or
abroad,
are warmly welcome to visit our company !
3. How does your factory do regarding quality control?
Quality is priority. Shunda people always attach great importance
to quality
controlling from the very beginning to the very end:
1).All raw material we used are environmental-friendly;
2).Skilful workers care every details in handling the producing and
packing processes;
3).Quality Control Department specially responsible for quality
checking in each process.
4. Will you teach how to use the machine?
Yes, engineers available to service machinery overseas or learn in
our factory.
5. How about the shipment?
Normally 35-45 days after confirming order, detail delivery date
should be decided according to
production season and order quantity.
6. Which payment term do you accept?
T/T, L/C
7. Do you have warranty?
1 year for electronic parts from shipment date
3 years for mechenical parts from shipment date
8.Do you have OEM/OEM service?
Yes, OEM/ODM service are available here. We can make some changes
on machine according to your requirements.
