Automatic High Speed Paper Cup Forming Machine For Cold Drink And
Hot Drink Cups Improve With Hot Air System
Description:
Single PE coated paper cup machine is the automatic environmental
machine with multi-running positions. This machine runs a whole
procedure of paper-feeding, cup-fan-wall sealing, oiling,
bottom-punching, heating, rolling, rimming, rounding and tripping.
It is an idea equipment of producing drinking cup, ice-cream cup
and other food cone-shaping containers. This type paper cup machine
mainly used to making one side PE coated paper cups from 4oz to
46oz.
Specifications:
| Model | SMD-90 |
| Speed | 100-120 pcs/min |
| Cup size | Top Diameter: 60mm(min)-125mm(max) |
| Bottom Diameter: 45mm(min)-100mm(max) |
| Height: 60mm(min)-170mm(max) |
| Raw material | 135-450 GRAM |
| Configuration | ULTRASONIC & HOT AIR SYSTEM |
| Output | 12KW,380V/220V,60HZ/50HZ |
| Air compressor | 0.4 M³/Min 0.5MPA |
| Net weight | 3.4 TONS |
| Dimension of machine | 2500×1800 ×1700 MM |
| Dimension of cup collector | 900 ×900 ×1760 MM |
Cup size
Advantages
Full automatic
Automatic control adopts optically controlled non-contact switch
Micro-controlled transducer
Step-less speed adjustment
Paper Cup-fan-wall body sealed by heater
Paper Cup bottom sealed by heater.
Easy changing molds produce different sizes paper cups
Easy operating by operator (one operator is enough)
Easy maintenance with minimum cost
Cheap operating cost and low investment
Paper cup making process
FAQ
1. Q: Is your company a factory or trading company?
A: Our company is a factory.
2. Q:Where is your factory located? How can I visit there?
A: Our factory is located in haining City, Zhejiang Province,
China, about 1.5 hours by car from Shanghai .All our clients, from
home or abroad, are warmly welcome to visit our company !
3. Q: Which kind of certicate do you have ?
A: We Have CE ,ISO:9000 certificates.
After Service
1. warranty:3 years
2.the guide booklet will be sent with machine to guide the
installation process works,adjust the whole
machine,production,avoide or solve the problem which the buyer will
face.
3.we will adjust the machine well for one week before the
delivery,ensure the machine has the perfect performance.
4.we can dispatch technologists to buyer's factory,guiding
installation,ajustment for a period,the buyer incharge of the
salary,traffic fee,boarding and lodging,communication and Daily
salary.
