Ultrasonic Sealing Ice Cream Cup Making Machine With High Speed
advantage:
1. photoelectric tracking can check every part and report.It can
detect the cup rim and cup bottom.such as unstuck
stain,broke,curl.Imported from Japan by panasonic.
2. Shunda’s Base board is nearly double than others,guarantee the
machinery working stable ,longer using.
3. 2sets of original hot air system guarantee the stability of
heating.Imported fom Switzerland by Leister.
4. We use Ultrasonic to heat the paper body,make the glue more
stronger.
5. Servo motor control the gap of the bottom-paper within 0.1mm.And
it will not skew,keep the distance same between the two sides of
the bottom-paper.From Taiwan by TECO.
6. camera system can inspect the cup situation.If the cup is
standard,it will blow into this tube,the defective production will
blow into this tube.
7. Automatic Oil lubrication system for the machien’s moving
parts,which is very useful,cause the worker don’t have to operate
it every day,It save many time ang promote the efficiency and the
life of the machine.
8. one labor can operate multi machine at same time,decrease the
artificial cost.
.............
picture:
detail:
| MODEL | SMD-90 |
| Speed | 100pcs/min |
| Cup size Range | <16oz |
| Material | Single and double PE coated paper |
| Heating system | Ultrasonic &hot air system |
| Output | 380V,4 KW ,60HZ, Three Phase four wire |
| Net weight | 3.4 TONS |
| Machinery Size | 2500 *1700*1600 MM |
| Paper request | 135gsm-450gsm |
| Warranty | 3 Years |
| Description | smd-90 paper cup machine is a high gram paper cup shaping machine,
it runs a whole procedure of the paper feeding, gluing, oiling, and
bottom punching, heating, rolling, rounding, and tripping.It is an
automatic machine you can control the speed according to the
production!
For a better cup body and bottom connection, it used ultrasonic and
two hot air for heating, the heating phase into three steps,
advanced technology allowed facility more safty both on itself and
operator.It is an ideal equipment to make the paper cups for hot
drink, cold drink, and ice cream paper cups.
We supply 2 year used spare parts for free. |
|
|
|
|
About us
Haining Chengda Machinery Co.,LTd estabilished in 1999,already 17
years,ship to more than 100 countries.Our company always abides by
the business strategy of "high-quality products & reasonable
price", the service concept of "showing respect to you & trying my
best", and the professional spirit of ’’honesty, innovation,
enthusiasm, sureness" to provide customers the best products and
services.
Why Choose Us
♦ Advantages
- Quality assurance both for our products and service for
after-sales.
- Favorable price.
- Great variety of products.
- Attractive design.
- Environment Friendly Technology
- OEM and ODM service provided.
♦ Our QC team
A QC team with more than 10 professional and technical personnel.
To ensure 100% products checking.
Material: Strictly control of material using, meet international
requested standards.
Semi-finished products inspection: Product inspection before 100%
finished.
Production line test: With work team or data engineer who will
inspect machines and lines at fixed period.
Finished Product Inspection: Quality and property test before
products are packed and loaded.
FAQ
1. Q: Is your company a factory or trading company?
A: Our company is a factory.
2. Q:Where is your factory located? How can I visit there?
A:Our factory is located in haining City, Zhejiang Province, China,
about 1.5 hours by car from
Shanghai .All our clients, from home or abroad, are warmly welcome
to visit our company !
3. Q:How does your factory do regarding quality control?
A:Quality is priority. Shunda people always attach great importance
to quality controlling from
the very beginning to the very end: 1).All raw material we used are
environmental-friendly; 2).Skilful workers care every details in
handling the producing and packing processes;
3).Quality Control Department specially responsible for quality
checking in each process.
