Technical date:
| Model | SMD-90 | | | | | Capacity | pcs/min | 100-120 | 90-110 | 80-100 | | Size Range | mm(max) | Top diameter:90
Bottom Diameter:80
Height:140 | Top diameter:110
Bottom Diameter:80
Height:170 | Top diameter:125
Bottom Diameter:100
Height:170 | | Suitable Paper Thickness | gsm | 135-450 | | | | Sealing Method | | Ultrasonic and hot air system | | | | Running Power | KW | 10 | 11 | 12 | | Air compressor | | 0.4m²/Min. 0.5MPa | 0.5m²/Min. 0.5MPa | 0.6m²/Min. 0.5MPa | | Net weight | Kgs | 3400 | 3500 | 3600 | | Machine dimension | mm | 2500*1800*1700 | 2600*1800*1800 | 2700*1800*1800 | | Collector Dimension | mm | 900*900*1760 | 1000*900*1860 | 1100*900*1860 |
|
Advantage:
1.Electric heating for single PE coated paper,and we use oblate to
make the paper cup body more better.
2.Quenching treatment for all the machinery,so its hardness is much
more better than others by 20%.
3.One machine with one mold for free, the mold size according to
buyer’s
4.Divided box: 125’ type, it has the long life than 100’
5.Our material of mould is steel anti-rust treatment.
6.Shunda use quenching skill to make the cam,is more harder and
having longer life.
Applications
Installation Service
1.oversea engineer support is available 2.Free training in Chengda
factory 3.Video and drawing support service
Our company
Haining Chengda estabilished in 1999,already 17 years.We have
almost 80% market in North Africa,also have client in
UAS,Mexico,Brazil,Finland,Iran,Saudi Arabia,,,You can be at ease
about our quality.
We support 3 years warranty and free training.You can come to our
factory to learn how to intall the machine,adjust the
machine,maintain the machine,we also can dispatch the engineer to
your factory.
Why Choose Us
♦ Advantages
Quality assurance both for our products and service for
after-sales.
Favorable price.
Great variety of products.
Attractive design.
Environment Friendly Technology
OEM and ODM service provided.
♦ Our QC team
QC team with more than 10 professional and technical personnel.To
ensure 100% products checking.Material: Strictly control of
material using, meet international requested standards.
Process:
Paper roll-----printing machine------printed paper ------cutting
machine-----paper fan------paper cup making machine------paper
cups.
