Ultrasonic Heating Double Wall Paper Cup Making Machine For Hot
Drink Cups
Technical Data:
Model SMD-80A
Speed 80-100 pcs/min
Cup size Top Diameter: 100mm(max)
Bottom Diameter: 80mm(max)
Height: 140mm(max)
Raw material 135-450 GRAM
Configuration ULTRASONIC
Output 10KW,380V/220V,60HZ/50HZ
Air compressor 0.4 M³/Min 0.5MPA
Net weight 3.0 TONS
Dimension of machine 2500×1800 ×1700 MM
Dimension of cup collector 900 ×900 ×1760 MM
Advantages:
1.It has 2 sets of original imported hot air system Leister
guarantee the stability of heating.
2.Ultrasonic seal the paper cup body,can produce both single and
double PE coated paper.
3.Open cylindrical can divide locating,heigh precision.
4.Automatically Oil lubrication system .
5.Servo motor control the gap of the bottom-paper within 0.1mm.
6.Gear and open cylindrical promote the stability and speed.
Finished products:
Output counting:
| Normal Running Speed | 90 pcs/min | 50 pcs/min | 40 pcs |
| 1 Day(12 Hours) | 90pcs*60min*12hours=64800 pcs | 50pcs*60min*12hours=36000 pcs | 28800pcs |
| 1 Week (5 Days) | 64800pcs*5days=324000pcs | 36000pcs*5days=180000pcs | 144000pcs |
| 1 Mouth(22 Days) | 64800pcs*22days=1425600pcs | 360000pcs*22days=792000pcs | 633600pcs |
About us:
Haining Chengda Paper Cup Machinery CO.,Ltd is established in year
1998, as Chinese earliest paper cup machine
manufacturer--design,research,manufacture,sell and serve , we have
developed, matured and specialized in machine types as below,
--Middle speed paper bowl machine SMD-80B 70-80cups/min
--Middle speed double wall paper cup machine SMD-80A 80-100cups/min
--High speed paper cup machine SMD-90 100-120cups/min
With decade years of technology accumulation,advanced manufacturing
skills and thoughtful after-sale services, Chengda(Shunda) Paper
Cup Machinery CO., Ltd has self-supported import and export right
and goes though CCC and CNAS certificates,also get CE and ISO9001
certified.
We have been supported hundreds of paper cup factories around the
globe,especially enjoy high reputation in USA,Finland,Algeria,etc.
We are always holding the faith of “quality wins market,honest wins
trust”. And in the future we should increase technology
creation,focus on improving manufacturing skills and lead trend of
paper cup machine industry.
COMPANY CULTURE
Consistent Concept, Achieve Centennial Chengda
Every company that has a dream of a hundred years needs employees
with the same spirit, and every corner is infused with the essence
of corporate culture. At Chengda, we have a good vision and work
hard for it; in Chengda, we have a business philosophy of honesty
and implementation, and in Chengda, we have a technical philosophy
of innovation and introduction. To every new project research and
development; in Chengda, we have a refined and rigorous production
concept, and through the production, assembly and testing of each
component; in Chengda, we have an efficient concept of work, a
harmonious teamwork spirit, and Infiltrate into every business
activity.
Vision: Leading the industry trend and achieving a century-old
enterprise.
Concept: Integrity, innovation, rigor, and efficiency.
Mission: Provide turnkey solutions for the paper container
manufacturing industry.
Goal: Technology leader in the global paper container molding
machine industry
FAQ:
1. Q: Is your company a factory or trading company?
A: Our company is a factory.
2. Q:Where is your factory located? How can I visit there?
A:Our factory is located in haining City, Zhejiang Province, China,
about 1.5 hours by car from Shanghai .All our clients, from home or
abroad, are warmly welcome to visit our company !
3. Q:How does your factory do regarding quality control?
A:We hold firm faith that quality comes first,and promise 3 YEARS
warranty.
Because our debuggers test and adjust every machine for 1 week
before packing and shipping out of workshop, no compromises on
quality.
4. Will you teach how to use the machine?
Yes, engineers available to service machinery overseas or learn in
our factory.
5. How about the shipment?
Normally 30-40 days after confirming order, detail delivery date
should be decided according to
production season and order quantity.
6. Which payment term do you accept?
T/T, L/C
7. Do you have warranty?
1 year for electronic parts from shipment date
3 years for mechenical parts from shipment date
8.Do you have OEM/OEM service?
Yes, OEM/ODM service are available here. We can make some changes
on machine according to your requirements.
1. Price term: FOB ShangHai Port, China
2. Payment term: T/T (30% as deposit, 70% balance before delivery)
or L/C
3. Delivery term: 30-35 working days after received deposit and
confirmed cup size
4. After sale service:
- The Operation Guidance, Manual Instruction and Electrical
Schematic Diagram will be
sent with machine to guide the installation process works, adjust
the whole
machine,production,avoid or solve the problem which the buyer will
face.
- We will adjust the machine well for one week before the delivery,
ensure the machine has
the perfect performance!
- We supply the free training of buyer, the training won’t stop
until the buyer control the
whole lesson. The cost of air ticket, boarding and lodging should
provided by buyer.
5. Warranty
- one year for electronic parts from the shipment date
- three years for mechnical parts from the shipment date
